Curved Tube Pressure Balance Corrugated Compensator factory introduced the design process of the product
Release time:
2021-09-15
The Curved Tube Pressure Balance Corrugated Compensator factory tells you that when the flow bellows deflect laterally, there is no change in volume, so the balance bellows only need to contain the appropriate number of convolutes needed to absorb the axial movement of the system. The only axial forces to be considered in the design are the force bellows and the balance bellows required to move the fluid.
The Curved Tube Pressure Balance Corrugated Compensator factory tells you that when the flow bellows deflect laterally, there is no change in volume, so the balance bellows only need to contain the appropriate number of convolutes needed to absorb the axial movement of the system. The only axial forces to be considered in the design are the force bellows and the balance bellows required to move the fluid.
The most common application for this type of curved tube pressure balance bellows compensator is adjacent to equipment such as turbines or pumps where allowable nozzle loads force the removal of pressure thrust.
For a single elbow joint, when it is subject to axial and lateral motions at the same time, the anchor at the end of the pipe and the anchor on the machine are all intermediate anchors and only need directional guidance. Curved Tube Pressure Balance Corrugated Compensator factory tells you: through proper design, the guide rail directly above the equipment can absorb the axial movement force of the expansion joint without imposing these forces on the equipment. The only force applied to the equipment is that required to deflect the expansion joint laterally.
