Flange Metal Hose

Keywords:

Flange Metal Hose

Whatsapp:

Mail:

Description
Parameters

- 商品名稱: Flange Metal Hose
Stainless steel pressure-resistant metal hose is a stainless steel corrugated pipe braided with one or more layers of steel wire or steel belt mesh sleeves, with joints or flanges at both ends, and is a flexible element used to transport various media. Its characteristics are: corrosion resistance, high temperature resistance, low temperature resistance (-196 ℃ ~ +420 ℃), light weight, small size, good flexibility. Widely used in aviation, aerospace, petroleum, chemical, metallurgy, electric power, paper, wood, textile, construction, medicine, food, tobacco, transportation and other industries.

Metal hose is an important component in the connection pipeline of industrial equipment. Metal hoses are used as wires, cables, wire and cable protection tubes for automated instrumentation signals and civilian shower hoses, with specifications ranging from 3mm to 150mm. Small-diameter metal hose (inner diameter 3mm-25mm) is mainly used for the protection of optical ruler sensing line and industrial sensor line protection.
Flange metal hose specifications: (flange material: carbon steel flange, stainless steel flange 201/304/316L)

List of metal hose joints:
- Flange Metal Hose

Inner diameter[mm]	outer diameter [mm]	Tolerance +/- [mm]	Weight in tension +/-10% [Kg/m]	Minimum bending radius[mm]	Minimum radial load [N]	Minimum tensile strength [N]
4	6	0.1	0.034	15	800	320
5	7	0.1	0.039	17	835	340
6	8	0.2	0.044	19	875	360
7	9	0.2	0.049	20	930	380
8	10	0.2	0.056	22	975	400
9	11	0.2	0.063	25	1020	450
10	13	0.2	0.100	30	1060	500
11	14	0.2	0.110	31	1095	550
12	15	0.2	0.120	32	1140	600
13	16	0.2	0.130	33	1175	650
14	17	0.2	0.140	35	1215	700
15	18	0.2	0.150	37	1250	720
16	19	0.2	0.160	40	1290	760
17	20	0.2	0.170	45	1330	800
18	21	0.2	0.180	42	1470	890
19	23	0.3	0.212	40	1510	840
20	24	0.3	0.223	42	1545	890
21	25	0.3	0.235	45	1580	920
22	26	0.3	0.247	48	1620	940
23	27	0.3	0.258	52	1655	960
24	28	0.3	0.269	55	1690	980
25	29	0.3	0.280	58	1735	1000
26	30	0.3	0.292	60	1770	1020
